Topcon LS-80X Long Range Laser Receiver Sensor w/ Holder 6 - 1054518-01

Topcon LS-B200W Wireless Machine Control Laser Receiver

Model Number: 1063574-04

The Topcon LS-B200W Laser Receiver is a versatile and wireless solution for grading, excavation, and alignment tasks. Designed for seamless integration with machine control systems, it offers precise laser detection, rugged durability, and advanced wireless communication capabilities. This receiver enhances productivity and accuracy, ensuring operators stay connected and on track during every phase of their project.

Features:

• LS-B200W Step2 will also include ISO Certification 13766-2
• New feature: Only the new Step2 LS-B200W will be able to have both CAN and BT (the "W" for wireless)
• Ruggedized for a variety of 2D applications
• LEDs for heads up visual operation
• Grade indicators to verify design grade
• High / Low marks for instant notification to grade
• Flexible 360° orientation for faster field work
• Optional audio indicators

Specifications:

• Detection Range: 360° laser detection coverage
• Operating Range: Up to 2,600 feet (with compatible laser)
• Accuracy Settings: Fine, Medium, Coarse (user-selectable)
• Wireless Communication: Integrated Bluetooth or radio connectivity
• Battery Life: Approximately 120 hours of continuous operation
• Power Supply: Standard alkaline batteries or external power source Water and Dust Resistance: IP66 rated for rugged environments
• Operating Temperature: -4°F to 122°F (-20°C to 50°C)
• Dimensions: 7.8 x 5.1 x 2.2 inches (198 x 130 x 56 mm)
• Weight: Approximately 2.3 lbs (1.05 kg)
