Topcon RL-H5A Self-Leveling Laser PS.DB Kit w/ LS-80X Receiver, 13ft Grade Rod 10ths and Tripod - 1035258-01

Topcon RL-HV1S Single Grade Laser w/ LS-80X Receiver

Model Number: 1051612-08

Features:

• The Topcon RL-HV1S Single Grade Laser w/ LS-80X Receiver is designed to be rugged and compact, providing maximum durability and value for your money.
• Suitable for a wide range of applications, including horizontal, sloping, and vertical laser applications, the RL-HV1S is capable of slopes up to ±15% in the X-axis. You can even turn it on its side for layout and alignment applications.
• With its exceptional long-range operation, the RL-HV1S is capable of shooting elevations up to 400m from your laser, covering an 800m (diameter) jobsite. Plus, you can operate it remotely from your smartphone with a range of 100m for horizontal operation and 20m for vertical operation.
• The standard HV1S kit includes the Topcon LS-80X hand receiver and Dry alkaline Batteries (lasting up to 120hrs), providing everything you need for a seamless laser experience.
• Designed to withstand even the toughest job site conditions, the RL-HV1S boasts an IP66 rating, meaning it can handle dust, sudden showers, and even torrential rainfall. And with Topcon's 5-year warranty, you can trust in the accuracy and reliability of this incredible laser.
• Features Bluetooth Laser Manager (app download). Compatibility for iOS and Android provides wireless remote control using a cell phone to adjust slope and check calibration. No special remote control needed.

Specifications:

• Accuracy H: ±10 arc seconds
• Self-Leveling Range: Horizontal/Vertical ±5°
• Grade Single: ±15%
• Working Area: 800m or more (diameter)
• Rotation Speed: 300, 600 rpm (selectable)
• Topcon Laser Manager App: Bluetooth 5.0
• Range: Horizontal 100m/Vertical 20m
• Battery Duration: 120hrs
• Operating Temp.: 20ºC to 50ºC
• LS-80X Hand Receiver: ±1mm & 2mm
• IP Rating: IP66
• Warranty: 5 Years
• Net Weight (kg): 7
• Product Length (mm): 440
• Product Width (mm): 260
• Product Height (mm): 390
• Includes:
• Topcon RL-HV1S Single Grade Laser Level
• Topcon LS-80X Hand Receiver
• Topcon (Holder 6) Receiver Clamp
• 4 x D-Cell Alkaline Batteries and charger
• Carry Case
• Australian Calibration Certificate
• Operator Manual

*Tripod not included.
